Made in Sweden
Cibes elevators are high-quality lift products that are designed and manufactured in our factory in Sweden.
Space-efficient platform lift
If you are looking for a versatile, user-friendly and space-saving platform elevator, the Cibes A5000 is a great solution. Just as suitable for residential as for public and commercial applications, this lift model is a go-to choice for many of our loyal customers in the building industry.
One of the main reasons is that the all-inclusive, ready-made lift concept is incredibly space-efficient and easy to install, requiring only minimal building alterations. In fact, it is possible to install a 2-stop Cibes A5000 lift in as little as 2-3 days.
All-inclusive platform lift
The passenger lift is delivered in ready-made elements with everything you need for installation, including the shaft.
Design options
Thanks to its many design options, it is easy to make the Cibes A5000 platform match your taste and sense of style.
Wheelchair accessible elevator
The standard sizes of the Cibes A5000 platform lift are big enough to accommodate wheelchairs, walkers and strollers.
Easy to integrate
Thanks to the compact, ready-made design it is easy to integrate Cibes A5000 platform lift into existing buildings. Because the lift is delivered in ready-made elements, requiring neither a deep lift pit, nor top machinery, the construction work is minimal.
You do not even need to build an elevator hoistway, as the Cibes A5000 always comes with a prefabricated lift shaft in steel or glazed panels.
Blends in seamlessly
Although the Cibes A5000 is always delivered with a prefabricated elevator shaft, it is just as easy to install it in an existing or site-built shaftway. This is an elegant solution that makes your lift blend in seamlessly into its architectural surroundings.
In addition, this is a lift model that offers you a wide choice of lift colors, door models, flooring options and other features, enabling you to create a lift design true to your vision.
Home lift solutions
More and more people in the United States are enjoying the comfort and beauty the Cibes A5000 is adding to their homes. A residential elevator does not only take passengers and wheelchairs, but allows you to move groceries, laundry baskets and cleaning equipment between floors, without breaking sweat.
Public and commercial settings
A platform elevator not only makes your facilities accessible to your customers and visitors, but it can also be of great service to your staff, making daily tasks, such as moving equipment between floors, easier to perform. The Cibes A5000 is a popular choice for stores, hotels, restaurants, offices and public buildings.
Lift interior
The Cibes A5000 operates with hold-to-run operation inside the elevator. You just maintain pressure on the floor button to travel and release it to stop.
This elevator model has a rated load of 880 lbs and can take 4-5 passengers. Because it is a platform elevator, regulations require it to travel at a reduced speed of max 30 FPM.
However, reduced speed also comes with advantages. Whereas high-speed elevators need big and bulky shaft structures to absorb the speed-generated forces, the Cibes A5000 only needs our space-saving, ready-made shaft.
Standard equipment for the Cibes A5000
The standard equipment of the Cibes A4000 includes features such as:
- Ready-made elevator shaft in steel panels (glazing is optional)
- Panoramic steel doors with tempered and laminated safety glass and concealed door closers
- Emergency telephone, emergency stop and alarm button
- Large and user-friendly platform controls
- Safety edges on all sides of the platform
- Soft stop and start for smooth lift operation
- Battery emergency lowering system
For more information about our standard and optional features, please contact your local Cibes Symmetry dealer.
Easy to install
Installing the Cibes A5000 platform lift is a lot easier than you might think. Because the vertical elevator is delivered in ready-made elements, it can be assembled within 2-3 days. In addition, the drive unit and machinery are so compact that they fit inside the shaft. That means that there is no need for a separate machine room, top machinery or a deep pit, which reduces your building costs.
No elevator pit
No top machinery
Lop top height
Integrated machine room (MRL)
Wheelchair-friendly elevator
The standard sizes of the Cibes A5000 platform elevator, 39.37″ × 57.76″ or 43.31″ × 57.76″ are big enough for passengers using wheelchairs, walkers and strollers. The largest platform size, 39.37″ × 77.56″, is even large enough for most mobility scooters.
We also offer a great selection of different accessibility options, such as concealed automatic door openers, extra large call buttons, lap-held IR controls and more.
Cibes A5000 - The perfect school elevator
The hold-to-operation makes the Cibes A5000 platform elevator very safe to use, even for small kids. In addition, the platform is equipped with safety edges and an emergency stop button, that bring the lift to an instant halt, as soon as they are activated.
Because the Cibes A5000 platform elevator is so safe, it is a popular choice for schools and childcare centers.
Panoramic lift shaft
The Cibes A5000 platform lift is available with a panoramic elevator shaft, glazed on all sides, including the machinery side. This is a very elegant shaft solution that makes the most of your natural light and preserves the open and airy feel of your space.
Traveling on an open platform inside a fully glazed shaft is a unique experience, offering you a 360-degree view of your surroundings, without any sensation of confinement. Full glazing is also great for safety, given that passengers inside the elevator are visible at all times.
Cibes A5000 options & accessories
We want to make it easy for you to design an elevator that both has the look and the features that you need. Discover our wide range of colors, floor options, door models and accessories and start designing your perfect platform lift.
We color you happy
Some of our most popular elevator color options are compiled in our inspirational guide Color Me Happy. Dare to be bold and discover the impact that different colors and hues have on your interior design. We color you happy!
Find your closest dealer
Get in touch with your closest dealer to take the first step towards the elevator of your dreams.
EcoSilent drive
The EcoSilent drive system is an optional feature for the Cibes A5000 platform lift that provides you with great benefits. It not only reduces your energy consumption by up to 45%, but it also makes lift operation virtually soundless. To give you a few examples:
- Coffee machine – 60dB
- Bumblebee – 55dB
- Cibes EcoSilent – 40dB
- Quiet bedroom – 30dB
Made in Sweden
The Cibes A5000 platform lift is manufactured in Sweden. We offer more than 75 years of engineering and design experience, to provide you with the high-quality products and services that you deserve.
Sustainable elevator
91% of the lift is made of recyclable materials and all lighting solutions use LED technology. In addition, screw-driven elevators have a lifetime of about 25 years that can be extended with various upgrades.
High-quality maintenance
Our commitment lasts throughout the lifetime of your elevator and includes high-quality maintenance services. A well-maintained lift will perform better, last longer and need fewer replacements of parts.
Screw-driven lifts
The mechanics of a screw-driven elevator are extremely reliable and robust. To put it simply, the platform is attached to a drive nut moving up and down the lifting screw, powered by an electric motor.
Environmental product declaration (EPD)
The Environmental Product Declaration (EPD) is based on a Life Cycle Assessment (LCA) and provides a standard way of declaring product impact according to a global, standardized system. The Cibes A5000 platform lift has an EPD so that you can compare its environmental impact to the lifts of other manufacturers.
Not enough space inside?
If you do not have enough space for an elevator inside, the Cibes outdoor lift may be a solution. The outdoor lift is equipped to endure most weather conditions and can be installed almost anywhere on the outside of your building, or against your terrace.
The unique Cibes Air
The Cibes Air has a unique, intuitive lift design that speaks to your senses. While the platform design taps into your natural instinct to grab onto the handrail to operate the lift, the great choice of colors and materials is a real treat for your visual and tactile senses.
Specifications and model details
Technical information
- Installation:Indoor
- Rated load:880 lbs
- Power supply:230 VAC, 60 Hz, 16 AMP, Single-Phase
- Speed:Max 30 FPM
- Min headroom:90 5/8" (full-height door)
- Lift pit:0", 2", or 2 3/4"
- Drive system:Screw and nut
- Max travel:23 ft
- Max number of stops:4
- Lift controls:Hold-to-run
- Motor Power:3 HP
- Machine room:Machine room-less (MRL)
- Door configuration:Single hinged doors (L/R), Same side, Straight-through, or 90 degree
Complete specifications and lift sizes
Check out the full Complete specifications and model details of Cibes A5000.
